Unit Includes
- Hose
- Lance
- Trigger gun
- Nozzles: 15°, 25°, and 40°
- High-pressure soap injector
Limited Warranty
All units - 10yr Frame, 5yr Pump, 3yr Engine
Features
- 1750 RPM slow speed
- NEMA 4X electrical enclosure with rocker switch, hour meter and soap control switch
- High-pressure soap with metering valve
- Roll-down doors with lock
- Slide out motor pump tray
- Time delay shut-down
- Remote box ready wired
- Float tank
- Burner fuels: No. 1/No. 2 diesel or kerosene
- 1/2" Schedule 80 vertical coil
Optional Accessory(sold separately & available upon order)
| Part # | Description |
|---|---|
| 7100283 | Draft diverter |
| 7110785 | Auto start/stop shut-off |
| 7110510 | Wired NEMA 4X remote operating station |
Pumps
Udor® industrial triplex pump
- Forged brass manifold
- Thermal relief valve
- Ceramic-coated plunger sleeves
- External unloader with bypass hose
Frame
- Powder-coated for corrosion resistance
- Corrosion resistant, stainless steel vented panels
- Wall-mount
Hose
- 3/8" x 50' steel-braided Armor Hose®
Dimensions
- 65184, 65190, 65191 - L 52" x W 36" x H 51"
- 65246, 65247, 65286, 65283 - L 64" x W 36" x H 61"
